1. design concept
The appearance design of this equipment takes "function-driven aesthetics" as the core, and focuses on the three core requirements of sulfuric acid recovery process: efficiency, safety and environmental protection, to create a sheet metal process shell with both industrial hard core temperament and modern minimalist style. Through modular structure, human-computer interaction optimization and environmental protection material application, Hertz industrial design "science and technology to enable environmental protection" brand proposition.
Highlights of 2. structure design
Modular sheet metal frame
The split sheet metal splicing process is adopted, and the main shell is divided into three modules: protective layer, operation layer and interface layer, which is convenient for production, assembly and later maintenance.
The top inclined protective cover design can effectively prevent liquid splashing and strengthen the three-dimensional sense of the equipment.
Function-oriented modeling language
Streamlined diversion channel: The hidden diversion structure is embedded at the edge of the shell, which echoes the direction of the internal pipeline of the equipment, and has both practicality and visual unity.
Safety warning convex surface: the key operation area adopts concave sheet metal bending process and is matched with warning color block to strengthen operation safety.
Human-computer interaction optimization
The front embedded touch panel fits the human body's natural line of sight at a 15 ° tilt angle to reduce operational fatigue.
The lateral honeycomb heat dissipation hole array achieves efficient heat dissipation and EMC protection through geometric hollow patterns, taking into account industrial aesthetics and functionality.
3. material and process
Environmental protection sheet metal material selection
The main body is made of 1.5mm galvanized steel plate, and the surface is treated by electrostatic powder spraying. The acid and alkali corrosion resistance is improved by 40%, which conforms to ISO 12944 industrial anti-corrosion standard.
Seams using laser seamless welding process, sealing up to IP55 protection level, to adapt to the complex environment of chemical workshop.
Surface Treatment Details
Matte matte texture: reduce the equipment surface reflection, avoid strong light interference operation line of sight.
Two-color anodizing: Brand LOGO and functional logo are presented through etching process to ensure long-term use without fading.
4. color scheme
Main color: deep space gray (RAL 7021) with science and technology blue (Pantone 2945C), conveying professional and reliable industrial equipment attributes.
Adornment color: warning yellow (RAL 1023) is applied to key areas such as switches and emergency stop buttons to enhance safety recognition.
Environmental metaphor: The side panel is decorated with gradual green stripes, symbolizing the concept of resource recycling and ecological sustainability.
5. environmental protection design extension
Detachable recycling design
The shell modules are connected by glue-free buckles, and 90% of the materials can be recycled after disassembly.
Low carbon manufacturing
The sheet metal processing adopts the numerical control stamping process, the material utilization rate reaches 98%, and the waste of scrap is reduced.
Conclusion
Hertz Industrial Design redefines the visual standard of industrial environmental protection equipment through the shell of this sulfuric acid recovery equipment-injecting humanistic care into rigorous process logic and highlighting the green mission in the hard-core mechanical aesthetics. This design not only enhances the overall value of the equipment, but also becomes a visual carrier for customers to practice environmental responsibility.
