With the enrichment of sheet metal products, the demand for cabinet design is gradually increasing. As a professional industrial design company, we have designed many successful sheet metal product cases for our customers, such as 1U chassis design, 2U chassis design, photo printing terminal design, communication cabinet design, etc. Based on rich experience in chassis cabinet design, we have summarized several matters needing attention in design.

The cabinet design should do a good job in the electromagnetic shielding design of the product. Electromagnetic shielding is to prevent electromagnetic disturbance of electronic components in wave equipment and harm to human health outside the equipment shell. In CE/UL/3C and other certifications, electromagnetic shielding is an essential item. Solutions can be found from the perspectives of structural shielding, reliable grounding, shielding materials, etc.

The chassis cabinet design should ensure the mechanical strength of the product. Strength design is essential in mechanical design. Only by ensuring that the product has sufficient strength can it meet the reliability and service life, and avoid excessive design and waste of material costs. In mechanics, only the working stress of parts is less than the yield force of their materials, can their strength requirements be met.

The chassis cabinet design should meet the technical specifications of the product. The technical indicators of the product are the only basis for design, manufacturing and use, and are also the objective standards for testing the quality of the product. In order to correctly design the structure of the cabinet, it is necessary to go deep into the actual situation, study the technical indicators of the product in detail, understand the structure and use of similar products or similar types of products at home and abroad, and then determine the form of the structure.

In the appearance design, the cabinet design needs to fully consider the limitations of objective factors such as actual technology and technology. The beautiful appearance can undoubtedly add luster to the whole product, so the appearance design cannot be ignored. However, due to the unique forming process of sheet metal, it is not suitable to have complicated shapes. Therefore, experience is particularly important in appearance design to break through the traditional box shapes and facilitate manufacturing and processing.

In addition, there are many details that need to be paid attention to in the design of the chassis cabinet, such as the selection of materials, the treatment of surface technology, cost control and so on. These are all aspects that designers need to consider comprehensively, balance the advantages and disadvantages, and choose the best design scheme from them.
