Electronic design is an important content in the process of research and development and production of charging piles, and is the key to realize the function of charging piles. Through reasonable electronic design, it can provide effective guarantee for the normal operation of product functions, and can also improve the efficiency and life of product use, and even save resources and production costs. For example, the following successful charging pile electronic design case.

Electronic design is an important content in the process of research and development and production of charging piles, and is the key to realize the function of charging piles. Through reasonable electronic design, it can provide effective guarantee for the normal operation of product functions, and can also improve the efficiency and life of product use, and even save resources and production costs. For example, the following successful charging pile electronic design case.

Key Points and Highlights of Electronic Design of 1. Charging Pile
1, safe and reliable, perfect fault exception protection function;
2. The function is comprehensive and can flexibly support different function extensions.
Electronic Design and Implementation of 2. Charging Pile
1. Basic charging function: It has automatic and manual charging functions, strong compatibility, and meets various charging modes of AC charging;
2. Enhanced charging function: it has the functions of charging by time, charging by electricity, charging by appointment time, automatic charging and manual charging;
3. Signal detection function: output detection, ic card detection, metering detection, emergency stop detection, network detection, switching value and other input information detection and running status detection, fault detection;
4. Human-computer interaction function: it can be equipped with 4.3, 5.7, 7.0, 8.0 and 10.0 inch industrial control touch screens;

5. Payment function: The charging pile is equipped with two-dimensional code mobile phone scanning payment function and IC card reader, which can be swiped for payment at the same time.
6. Safety protection function: AC input overvoltage, undervoltage, overcurrent, leakage, short circuit, lightning protection, charging connection abnormal protection, insulation detection and other protection;
7. Communication Protocol: BMS Communication Protocol Meeting National Standards
8. Background communication interface: industrial Ethernet port, RS485, GPRS,3G/4G, (CAN port can be configured)
9. Charging interface: one gun for one machine and two guns for one machine; 10. Charging power: 3.5kw, 7.0kw and 15KW for AC charging piles.
Of course, in order to realize the expected functions of the charging pile, in the process of electronic design, our electronic R & D team has carried out bold exploration and innovation, and the functional parameter requirements of the product have been tested and tested many times to ensure the design The various performance parameters of the electronic hardware meet the national industry standards, providing reliable hardware support for the research and development and production of charging piles.
