Corrigan Modular Water Bottle | Product Appearance Design

Comment

Comment Board （20）

郝吉 2024-01-17

Super iron powder came to report

戴不动🏄 2024-01-08

How to get out of the lid? If the wall thickness of the plastic parts is uneven, it is easy to shrink.

如花 2024-01-08

Add the slider and turn it upside down, and you can get everything done with the mold and money.

戴不动🏄 2024-01-08

As shown in the figure, how does the slider go? The big one is big and the small one is small, and the big one has no parts, so the inner slider can't be made, can it?

如花 2024-01-09

Can make, you can ask your mold colleagues

如花 2024-01-09

The main reason is that it is expensive, the yield and efficiency are very low, and the mold is easy to break after long injection time.

蔡玮 2024-02-16

With three to four plate dies, the parting line is placed at the middle edge of the R side of the shape, and the front die is only placed at a shallow position.

May 2024-11-01

I think this is mainly a conceptual design. It is good to look at the shape and appreciate it. The design does not consider mass production and practicality. If you really want to mass produce, you have to disassemble the parts after the shape is optimized.
